SDR331PUR
Pur hot melt adhesive dispensing machine is suitable for mobile phones, tablet computers and other electronic products. It is equipped with temperature control system and adopts double zone heating to eliminate uneven heating phenomenon, so as to ensure stable glue output. All brands of structural adhesives can be used.
- Overview
- Specifications
1. Constant temperature heating is adopted to eliminate heating unevenness.
2. All brands of PUR glue can be used.
3. Single zone heating and double drive heating are optional.
4. Preheating device can be selected to preheat in advance to save operation time.
規格型號 | SDR221PUR | SDR331PUR | SDR441PUR | SDR551PUR | SDR651PUR |
加工范圍X/Y/Z | 200×200×50 | 300×300×100 | 400×400×100 | 500×500×100 | 600×500×100 |
負重XY/Z | 5KG/3KG | 11KG/6KG | |||
移動速度XY/Z | 500/350mms | 800/350mms | |||
重復精度 | ±0.02mm軸 | ||||
資料記錄能力 | 至少100組、每組4000點 | ||||
資料存儲方式 | CF卡 | ||||
資料運算速度 | 32bit | ||||
顯示方式 | LED | ||||
馬達系統 | 日本微步進電機 | ||||
傳動模式 | 同步帶 | X/Y軸同步帶 Z軸絲桿 | |||
直線圓弧運動模式 | 3軸（立體空間任意路徑皆可） | ||||
教導模式 | 教導盒 | ||||
I/O訊號 | 8進/8出 | ||||
外部控制界面 | RS232 | ||||
輸入電源 | 全電壓 AC100-230V,300W | ||||
工作環境溫度 | 10-40° | ||||
工作環境濕度 | 20-90%無凝露 | ||||
機臺尺寸 | 385×380×500 | 485×505×610 | 585×610×610 | 685×700×610 | 785×700×610 |
機臺重量 | 23kg | 32kg | 41kg | 52kg | 56kg |
